Custom Planar Magnetics will transform the way you think about power. All our inductors and transformers are built from custom designs using superior ferrite cores and pre-formed windings. This means greater repeatability and tighter control of parasitics. They’re tailored to purpose and engineered to perfection.

+44 (0)1575 578 006

view products

What are Planar Transformers?

High Durability & Performance

Rapid response rates

Quotes delivered fast & on target

Custom Planar Magnetics

Custom Planar Transformers specialise in the design and manufacture of high quality custom planar transformers and inductors. We are based in the UK and are strategically placed to service the global electronics market.

We design and manufacture for a variety of end-user applications ranging from Battery Charging & Welding to Aerospace & Automotive.

Select your transformer

Product Selector

Custom Planar Magnetics would like to make purchasing a transformer as easy as possible. Use our interactive power selector to select power ratings, low to high.

Pre-formed Copper

Greater repeatability & tighter control of parasitics

Size is everything

Higher efficiency, higher performance & highly adaptable

Qualified to Military and Aeropsace standards

40 layers of 6oz copper embedded inside a single, sealed PCB. High, secure performance in rugged environments

What they say

“The appeal of Custom Planar Magnetics is obvious: low leakage inductance; excellent repeatability of performance; economical assembly; mechanical integrity; and superior thermal characteristics.” — Paul Carden, Renaultsport F1

Learn More

Connections

Custom Planar Magnetics offers a superior range of connections. From Pins to Threaded Inserts our highly efficient connections can adapt to even the most challenging demands & currents. CPM will provide the stability and reliability needed to keep the job on task.

Connections

Guaranteeing optimum power results

3D CAD Design

Simulated & tested in full prior to deployment

Precision Engineering

Skilled engineers passionate about their work

400 -1 500 watts

Power Range 100

view full list

2200 - 6000 watts

Power Range 200

view full list

8000 - 30,00 watts

Power Range 300

view full list

50000 - 130,00 watts

Power Range 400

view full list

Get in Touch

Cores

Ferrite and Powder cores are used as standard. Unlike other suppliers Custom Planar Magnetics can supply custom cores shapes and sizes when required by specific applications. We also build cores from block material to make new shapes.

Get in Touch

Heatsinks & Mountings

CPM can provide fixing plates and heatsinks for all transformer sizes. These come with a variety of different fixing holes. These are also anodized in a variety of corrosion-resistant colours, giving your tranformer just the right support with just the right finish.

Produced with pride

All CMP engineers are passionate about their work

Learn more

Design Services

From dealing promptly with initial enquiries to responding effectively to briefs CPM engineers will provide a first class design & modelling service. Custom Planar Magnetics believes that communication and not capital is the key to success

Heatsinks/Mountings

Heatsinks & Mountings for all transformer sizes

The power behind welding

CPM offer a range of SMPS welding transformers for high performance welding.

Automation

Working with Cobots to automate repetitive tasks

Faster than our competitors

CPM can ensure a quicker turnaround on design and production

Edge Wound Inductors
